Binder VD Vacuum Drying Ovens


Vacuum drying oven for non-flammable solvents


The VD series offers safe drying with homogenous temperature distribution, thanks to its APT.line™ air jacket system. Optimum heat transfer through patented expansion rack technology; the racks can be positioned as needed and are easy to clean.

In addition to these many features, the units have an individually programmable controller.

Features

  Electronically controlled APT.line™ preheating chamber technology with 2 patented expansion racks assures temperature accuracy and reproducible results
  Temperature range 15 °C (27 °F) above ambient temperature up to 200 °C (392 °F), optional up to 250 °C (482 °F) - not available for 115 V units
  MP controller with 2 programs with 10 sections each, or alternatively 1 program with 20 sections. Integrated week program timer with real time function. Digital temperature setting with an accuracy of one degree. Elapsed time indicator.
  Precision-adjustable ventilation valve (At VD 23 the standard inert gas connection is also used as ventilation valve.)
  Precision-adjustable inert gas valve with Cross-Flow-Technology
  Spring-mounted shatter proof safety glass panel
  All electrical componets are decoupled from the interior chamber
  Spring mounted safety glass panel with shatter protection
  Independent adjustable temperature safety device class 2 (DIN 12880), with visual temperature alarm
  Measuring port DN 16
  Analog pressure gauge (display pressure difference between the inner chamber and the ambient pressure)
  Electro polished inner chamber, suction and ventilation tubes, pressure container, expansion racks and ball valve are made of stainless steel
  Door gasket made of tempered silicone
  2 x 24 V DC (max 0.4 A) switching outputs, switched via 2 control contact of the program editor
  RS 422 interface for use with optional GMP/GLP and FDA guideline 21 CFR Part 11 compliant APT-COM™ DataControlSystem software
  2 patented, flexible aluminum expansion racks
  Available as complete system, with module and vacuum pump.
  Features reduced sound level, pactical working height and well balanced system.
  BINDER test certificate

Specifications


VD 23
VD 53
VD 115


VD 23


VD 53

Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.
