CTS High Pressure Composite Cylinders

Capacity (l) Pressure (bar) Length (mm) Diameter (mm) Weight (kg) Life
2 300 366 105 0,9 Unlimited
3 300 425 115 1,2 Unlimited
6,8 300 158 510 3,0 Unlimited
7,2 300 158 530 3,1 Unlimited
9 300 180 538 4,0 Unlimited

The cylinders above also include two rubber cups and a transparent thin sleeve.

Possible accessories for these cylinder include a valve assembly, a thick transparent sleeve, a thin yellow sleeve and a thick yellow sleeve.

CTS are also capable of producing all types of high and low pressure cylinders for the storage of liquified or gaseous gases up to a maximum working pressure of 750 bar. The volumes of the cylinders range from a minimum of 0.8 l up to a maximum of 260 l.

2l Datasheet
3l Datasheet
9l Datasheet
6,8l Datasheet
7,2l Datasheet

Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.
