Kingsmill Industries Bonded Connections


B BOND : FLAT SURFACES


Kingsmill 'B' type bond connections are designed to bond either copper or Aliminium conductor to flat metal surfaces.


CONDUCTOR SIZE(mm)CONDUCTOR MATERIALBOLT SIZEWEIGHT(Kg)PART No.
25 x 3COPPERM100.10BBCB
25 x 3ALUMINIUMM100.06BBAB



RWP BOND : PIPE WORK


Kingsmill RWP type bond connections are designed to connect flat conductor to circular objects i.e pipework and hand rails etc.


CONDUCTOR SIZE(mm)CONDUCTOR MATERIALBOLT SIZEWEIGHT(Kg)PART No.
25 x 3COPPERM100.18CRWB
25 x 3ALUMINIUMM101.08ARWB



TOWER EARTH CLAMP


Kingsmill tower earth clamps are designed to bond either copper or aliminium conductor to flat surfaces.


CONDUCTOR SIZE RANGE(mm2)DESCRIPTIONCONDUCTOR MATERIALWEIGHT(Kg)PART No.
25-50SINGLE PLATE TOWER EARTH CLAMPCOPPER0.09TEC2550
25-50SINGLE PLATEALUMINIUM0.06TEA2550
16-70DOUBLE PLATE TOWER EARTH CLAMPCOPPER0.13TEC1670
70-120DOUBLE PLATE TOWER EARTH CLAMPCOPPER0.22TEC70120



FLEXIBLE FLAT COPPER BRAID BOND (COPPER BRAID)


Flexible copper or flexible tinned copper braid terminated with pressed ferrult connector at each end, suitable for bonding gates, doors, fences etc.


OVERALL DIMENSIONS(mm)LENGTH (B)(mm)HOLE DIA. (A)(mm)CROSS-SEC AREA(mm2)WEIGHT(Kg)PART No.
12 x 12007.06.00.01FB200/6/7
12 x 14007.06.00.02FB400/6/7
15 x 1.52007.0100.02FB200/10/7
15 x 1.54007.0100.04FB400/10/7
19 x 2.52009.0160.03FB200/16/9
19 x 2.54009.0160.06FB400/16/9
25 x 320011250.05FB200/25/11
25 x 340011250.10FB400/25/11
25 x 3.520011350.09FB200/35/11
25 x 3.540011350.15FB400/35/11
30 x 520011500.10FB200/50/11
30 x 540011500.20FB400/50/11
32 x 620013700.13FB200/70/13
32 x 640013700.25FB400/70/13
37 x 620013950.19FB200/95/13
37 x 640013950.37FB400/95/13
45 x 6200171200.23FB200/120/17
45 x 6400171200.46FB400/120/17
50 x 8200171500.30FB200/150/17
50 x 8400171500.60FB400/150/17



FLEXIBLE FLAT COPPER BRAID BOND (TINNED COPPER BRAID)


Flexible copper or flexible tinned copper braid terminated with pressed ferrult connector at each end, suitable for bonding gates, doors, fences etc.


OVERALL DIMENSIONS(mm)LENGTH (B)(mm)HOLE DIA. (A)(mm)CROSS-SEC AREA(mm2)WEIGHT(Kg)PART No.
12 x 12007.06.00.01FBT200/6/7
12 x 14007.06.00.02FBT400/6/7
15 x 1.52007.0100.02FBT200/10/7
15 x 1.54007.0100.04FBT400/10/7
19 x 2.52009.0160.03FBT200/16/9
19 x 2.54009.0160.06FBT400/16/9
25 x 320011250.05FBT200/25/11
25 x 340011250.10FBT400/25/11
25 x 3.520011350.09FBT200/35/11
25 x 3.540011350.15FBT400/35/11
30 x 520011500.10FBT200/50/11
30 x 540011500.20FBT400/50/11
32 x 620013700.13FBT200/70/13
32 x 640013700.25FBT400/70/13
37 x 620013950.19FBT200/95/13
37 x 640013950.37FBT400/95/13
45 x 6200171200.23FBT200/120/17
45 x 6400171200.46FBT400/120/17
50 x 8200171500.30FBT200/150/17
50 x 8400171500.60FBT400/150/17



FLEXIBLE CIRCULAR COPPER BRAID BOND (COPPER BRAID)


Flexible copper or flexible tinned copper braid terminated with pressed ferrult connector at each end, suitable for bonding gates, doors, fences etc.


OVERALL BRAID DIMENSIONS (mm)LENGTH (B)(mm)HOLE DIA. (A)(mm)CROSS-SEC AREA(mm2)WEIGHT(Kg)PART No.
4.22007.06.00.01CB200/6/7
4.24007.06.00.02CB400/6/7
5.42007.0100.02CB200/10/7
5.44007.0100.04CB400/10/7
7.02009.0160.03CB200/16/9
7.04009.0160.06CB400/16/9
8.520011250.05CB200/25/11
8.540011250.10CB400/25/11
11.520011500.10CB200/50/11
11.540011500.20CB400/50/11
14.520013700.13CB200/70/13
14.540013700.25CB400/70/13
16.020013950.19CB200/95/13
16.040013950.37CB400/95/13



FLEXIBLE CIRCULAR COPPER BRAID BOND (TINNED COPPER BRAID)


Flexible copper or flexible tinned copper braid terminated with pressed ferrult connector at each end, suitable for bonding gates, doors, fences etc.


OVERALL BRAID DIMENSIONS (mm)LENGTH (B)(mm)HOLE DIA. (A)(mm)CROSS-SEC AREA(mm2)WEIGHT(Kg)PART No.
4.22007.06.00.01CBT200/6/7
4.24007.06.00.02CBT400/6/7
5.42007.0100.02CBT200/10/7
5.44007.0100.04CBT400/10/7
7.02009.0160.03CBT200/16/9
7.04009.0160.06CBT400/16/9
8.520011250.05CBT200/25/11
8.540011250.10CBT400/25/11
11.520011500.10CBT200/50/11
11.540011500.20CBT400/50/11
14.520013700.13CBT200/70/13
14.540013700.25CBT400/70/13
16.020013950.19CBT200/95/13
16.040013950.37CBT400/95/13


Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.
