Oldham GD10P Gas Detector

  Life-safety performance approved; ATEX EN60079-29-1 & CSA 22.2 No. 152
  15 year warranty IR sources - solid state optics
  T90 < 2s with option for selectable response rate
  Individually heated sapphire mirror (not conducted heat)
  No field recalibration
  Dual skin weather protector - no filters / gauzes or sinters
  Planned maintenance with HART
  SIL 2/3 certified

The GD10P has been designed with features that provide an effective response to the detection of gas hazards in a wide range of industrial environments from boiler plant rooms to offshore petrochemical installations.

These infrared gas detectors differ from all other models, because they utilize silicon based solid-state infrared sources. The complete optomechanical design and construction is so stable that an ultra fast speed of response can be achieved while providing unparalleled service life and detector stability, thus saving on maintenance and service costs.

We offer the longest combined detector and IR source warranty on the market.


For retrofit applications, a bridge interface is available allowing the detector to be connected directly to catalytic systems, using the existing cabling and control modules.

Supplied with worldwide performance and hazardous area approvals. Suitable for use in SIL 2 & SIL 3 systems.

An industry standard HART® interface is used for configuration of the optical fast response time and special fault levels as well as access to extended maintenance data.


Datasheet
Manual

Ordering Information


"Infrared Transmitter type GD10P
ATEX II 2G approved - delivered without cable-gland"


GD10-P00-17EG-0XH-00 GD10P Detector CH4 Methane 100% LEL (4.4% Vol.), SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2863)
GD10-P00-17DG-0BH-00 GD10P Detector CH4 Methane 100% LEL (5% Vol.), SS 316L, CSA, 4-20mA, source, HART (Config 2886)
GD10-P00-17DG-0BJ-00 GD10P Detector CH4 Methane 100% LEL (5% Vol.), SS 316L, CSA, 4-20mA, sink, HART
GD10-P00-17DG-0CH-00 GD10P Detector CH4 Methane 100% LEL (5% Vol.), SS 316L, UL, 4-20mA, source, HART (Config 2978)
GD10-P00-17DG-0CJ-00 GD10P Detector CH4 Methane 100% LEL (5% Vol.), SS 316L, UL, 4-20mA, sink, HART
GD10-P00-17DG-0XH-00 GD10P Detector CH4 Methane 100% LEL (5% Vol.), SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2873)
GD10-P00-17DG-0XJ-00 GD10P Detector CH4 Methane 100% LEL (5% Vol.), SS 316L, ATEX, IECEx, 4-20mA, sink, HART (Config 2867)
GD10-P00-17BG-0BH-00 GD10P Detector CH4 Methane 100% Vol., SS 316L, CSA, 4-20mA, source, HART (Config 3052)
GD10-P00-17BG-0XH-00 GD10P Detector CH4 Methane 100% Vol., SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2849)
GD10-P00-18BG-0XH-00 GD10P Detector CH4 Methane 100% Vol. (Biogas), SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2855)
GD10-P00-18BG-0XJ-00 GD10P Detector CH4 Methane 100% Vol. (Biogas), SS 316L, ATEX, IECEx, 4-20mA, sink, HART
GD10-P00-19DG-0XH-00 GD10P Detector CH4O Methanol 100% LEL, SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2891)
GD10-P00-19DG-0XJ-00 GD10P Detector CH4O Methanol 100% LEL, SS 316L, ATEX, IECEx, 4-20mA, sink, HART (Config 3055)
GD10-P00-02DG-0XH-00 GD10P Detector C2H2 Acetylene 100% LEL SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2905)
GD10-P00-03DG-0XH-00 GD10P Detector C2H4 Ethylene 100% LEL SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2879)
GD10-P00-03DG-0XJ-00 GD10P Detector C2H4 Ethylene 100% LEL SS 316L, ATEX, IECEx, 4-20mA, sink, HART
GD10-P00-05EG-0XH-00 GD10P Detector C2H6O Ethanol 100% LEL (3.1% Vol) SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 3021)
GD10-P00-05DG-0XH-00 GD10P Detector C2H6O Ethanol 100% LEL (3.5%Vol) SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2930)
GD10-P00-07DG-0XH-00 GD10P Detector C3H6 Propene 100% LEL SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2926)
GD10-P00-09EG-0XH-00 GD10P Detector C3H8 Propane 100% LEL (1.7% Vol.), SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2997)
GD10-P00-09DG-0BH-00 GD10P Detector C3H8 Propane 100% LEL (2.2% Vol.), SS 316L, CSA, 4-20mA, source, HART (Config 3015)
GD10-P00-09DG-0XH-00 GD10P Detector C3H8 Propane 100% LEL (2.2% Vol.), SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2872)
GD10-P00-09DG-0XJ-00 GD10P Detector C3H8 Propane 100% LEL (2.2% Vol.), SS 316L, ATEX, IECEx, 4-20mA, sink, HART (Config 2960)
GD10-P00-38DG-0BH-00 GD10P Detector n-C4H10 n-Butane 100% LEL, SS 316L, CSA, 4-20mA, source, HART (Config 2989)
GD10-P00-38DG-0CH-00 GD10P Detector n-C4H10 n-Butane 100% LEL, SS 316L, UL, 4-20mA, source, HART (Config 3038)
GD10-P00-38DG-0XH-00 GD10P Detector n-C4H10 n-Butane 100% LEL, SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2938)
GD10-P00-11DG-0XH-00 GD10P Detector C5H12 Pentane 100% LEL, SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 3010)
GD10-P00-13DG-0XH-00 GD10P Detector C6H6 Benzene 100% LEL, SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2943)
GD10-P00-73DG-0XH-00 GD10P Detector C6H12 Cyclohexane 100% LEL, SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2992)
GD10-P00-12DG-0XH-00 GD10P Detector C6H14 Hexane 100% LEL, SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2949)
GD10-P00-14DG-0XH-00 GD10P Detector C7H8 Toulene 100% LEL (1.2% Vol.), SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 3005)
GD10-P00-15DG-0XH-00 GD10P Detector C8H8 Styrene 100% LEL, SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 3062)
GD10-P00-23AN-0XH-00 GD10P Detector CO2 Carbon dioxide 10000 ppm, SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2841)
GD10-P00-23BH-0BH-00 GD10P Detector CO2 Carbon dioxide 3% Vol., SS 316L, CSA, 4-20mA, source, HART
GD10-P00-23BH-0XH-00 GD10P Detector CO2 Carbon dioxide 3% Vol., SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2845)
GD10-P00-23BC-0BH-00 GD10P Detector CO2 Carbon dioxide 5% Vol., SS 316L, CSA, 4-20mA, source, HART (Config 3018)
GD10-P00-23BC-0XH-00 GD10P Detector CO2 Carbon dioxide 5% Vol., SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2901)
GD10-P00-24BC-0BH-00 GD10P Detector CO2 Carbon dioxide 5% Vol. (CH4 immune), SS 316L, CSA, 4-20mA, source, HART (Config 2975)
GD10-P00-24BC-0CH-00 GD10P Detector CO2 Carbon dioxide 5% Vol. (CH4 immune), SS 316L, UL, 4-20mA, source, HART (Config 3046)
GD10-P00-24BC-0XH-00 GD10P Detector CO2 Carbon dioxide 5% Vol. (CH4 immune), SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2859)
GD10-P00-23BD-0XH-00 GD10P Detector CO2 Carbon dioxide 10% Vol., SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2934)
GD10-P00-23BG-0XJ-00 GD10P Detector CO2 Carbon dioxide 100% Vol., SS 316L, ATEX, IECEx, 4-20mA, sink, HART
GD10-P00-23BJ-0XH-00 GD10P Detector CO2 Carbon dioxide 25% Vol., SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2956)
GD10-P00-23BG-0XH-00 GD10P Detector CO2 Carbon dioxide 100% Vol., SS 316L, ATEX, IECEx, 4-20mA, source, HART
GD10-P00-24BG-0XH-00 GD10P Detector CO2 Carbon dioxide 100% Vol. (CH4 immune), SS 316L, ATEX, IECEx, 4-20mA, source, HART (Config 2909)

ACCESSORIES FOR GD10P

373-901337 Terminal GD10P/PE/L 4-5
373-903947 Terminal GD10P/PE/L 1-3
499-810913 Splash guard and Weather Protection, GD10P
499-816584 Back cover, kit GD10P/PE/L
540-903951 Ring Sealing (58x3) for Sample flow GD10P
540-903952 Ring Sealing (60x3) for Sample flow GD10PE
540-903954 Ring Sealing (65x2) for Back cover GD10P/PE/L
541-903950 Ex plug stopping M20
599-810646 Test nipple, GD10P
599-811937 Test nipple for GD10P Duct mount
599-904176 Protective Cap for test nipple GD10P/PE
499-810874 Sample flow housing for GD10P. This is also used for testing / Calibration check.
499-811938 Duct mounting kit for GD10P. Mounting flange and front cover.
499-813397 Mosquito net, GD10P, steel mesh
499-815712 Sunshade, GD10P/GD10PE
499-816867 Pipe mounting plate, kit GD10P, M8x2,5" A4 (for 2" pole)
6343489 Cable-gland kit, M20, stainless steel, for armoured cable
6343493 Cable-gland kit, M20, stainless steel, for unarmoured cable
6343495 Cable-gland kit, M20, nickelled brass, for armoured cable
6343499 Cable-gland kit, M20, nickelled brass, for unarmoured cable



Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.
