RAE Systems AreaRAE Steel Z2


Rapidly Deployable, Wireless Multi-gas Monitor


The AreaRAE Steel Z2 is a one- to five-gas wireless monitor that delivers ATEX Zone 2 certification in an extremely rugged stainless-steel enclosure designed for applications in harsh environments. The weather-resistant AreaRAE Steel Z2 is the benchmark against which portable wireless gas monitors are judged.

AreaRAE Steel Z2 combines a photoionization detector (PID) for parts-per-million measurement of volatile organic compounds (VOCs) with lower explosive limit (LEL) and oxygen sensor, plus up to two electrochemical toxic sensors for measuring specific substances such as hydrogen sulfide or chlorine. The AreaRAE Steel Z2 can also integrate a gamma radiation sensor in place of one of the electrochemical toxic sensors or the oxygen sensor.

An integrated wireless modem allows the AreaRAE Steel Z2 to transmit real-time sensor readings to a ProRAE Remote base station located up to 3 kilometers away.

The base station is a standard Windowsbased PC running ProRAE Remote software connected to a RAELink Host Modem. The base station can communicate with up to 12 AreaRAE Steel Z2s (or other AreaRAE-compatible monitors), providing a multi-threat detection network that can monitor a wide geographic area.

AreaRAE Steel Z2 monitors are powered by rechargeable Lithium-ion batteries that deliver up to 18 hours of continuous operation and can be powered by external 12-volt DC sources or from AC line power. They can also be powered by standard alkaline batteries with an optional alkaline battery adapter.

AreaRAE Steel Z2 options include the ability to track and display readings from remotely located detectors on a GPS map.

The AreaRAE Steel Z2 is ideal for HazMat and other emergency response monitoring programs. AreaRAE Steel Z2 detectors can be used to quickly establish an emergency perimeter by setting out multiple monitors at strategic locations, then backing off to a position of safety to monitor readings over the wireless link.

The AreaRAE Steel Z2 is available individually or as part of the Rapid Deployment Kit (RDK) system package.


Key Features

  Up to five sensors (PID, LEL, O2 and two toxic gas electrochemical)
  Loud buzzer and large, extra-bright warning light
  Large LCD display and keypad
  Rugged, weather-resistant stainless-steel housing
  Built-in sampling pump
  Interchangeable Lithium-ion or alkaline battery pack
  Continuous operation via AC source

Additional Advantages

  Real-time wireless data transmission with built-in RF modem
  View real-time sensor data and alarm status at headquarters or command center
  ProRAE Remote software simultaneously controls and displays readings for up to 12 remote detectors
  License-free, ISM wireless transmission with communication range up to 3 kilometers.
  Optional GPS provides ability to track and display readings from remote detectors

Applications

  HazMat and Emergency Response
  Refineries and Petrochemical Plants
  Power Plants
  Pulp and Paper Industry
  Plant and Mill Turnarounds
  Marine and Offshore Wells


Data Sheet
Manual

Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.
