Watson Smith VP50S 3-Way Proportional Pressure Control Valve

  Closed-loop air piloted proportional pressure control valve
  Fast response time with pressure output display
  High flow
  Excellent performance characteristics
  Adjustable gain
  Adjustable pressure range
  Low power consumption
  Feedback signal
  Manifold mountable

Technical Specifications

  Medium: Compressed air filtered to 5 μm, dry and non-lubricated
  Operation: Air piloted spool valve with integrated electronic pressure control
  Output pressure: 0 to 2, 0 to 6, 0 to 10 bar (or PSI equivalent)
  Supply pressure: Minimum 2 bar above maximum output required, 14 bar max.
  Supply sensitivity: Better than 0,75% span output change per bar supply pressure change
  Flow: Up to 1400 Nl/min max. (see characteristic curves)
  Response time: < 80 ms (from 10 - 90% of output pressure into a 0,1 litre load)
  Air consumption: < 5 Nl/min
  Ambient temperature: 0C to +50C. Contact our technical service for use below +2C
  Temperature effect: Typically better than 0,03% of span/C for span and zero over operating range
  Degree of protection: IP 65 in normal operation
  Display accuracy: Better than 3% of span
  Linearity: < 1%
  Hysteresis: < 1%
  Vibration immunity: < 3% output shift for 3 g 10-150 Hz
  Weight: approx. 0,30 kg



Find out more by reading our data sheet below:


Data Sheet

Please note, this product is not yet RoHS compliant.

Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.
