GMI PS500 GMI PS500 GMI PS500

GMI PS500

The GMI PS500 can be tailored to detect up to five gases with its toxic and catalytic sensors, photo ionisation detectors and infrared capabilities.

Key Features

  • Over 15 plug-and-play smart sensors to choose from
  • Wide range of VOC's with 2 different PID sensors
  • Flexible configuration to suit your specification
Get a Quote
GMI

Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.

  • • Piercing 95 dB audible plus 360-degree high visibility light bar
  • • On-board datalogging for calibration certificates, data management and event logging
  • • High impact rubberised case
  • • IP65
  • • Low cost of ownership

'Plug and Play' option allows the customer to 'plug in' a new board with a different gas range.

The PS500 is particularly useful in noisy environments, featuring a very loud (95dBA) penetrating and distinctive audible alarm together with high visibility large area visual alarm.

Pump, diffusion or both together, allowing pumped sample for pre-entry checking and diffusion in confined space working, thus maximising battery life.

A robust, moulded, rubberised casing guaranteeing Hi-Impact resistance, the PS500 can be used in the most demanding environments.

Applications

  • • Personal safety in confined space - H2S/O2/CO hazards
  • • General safety in confined space
  • • Shipping - general
  • • Shipping - fumigant
  • • Breweries - CO2 hazard
  • • Plant shutdown
  • • Permit to work systems
  • • Pressurised tunnelling
  • • Fleet auxiliary

General Accessories
  • 66123 Hand Aspirator (can be used for non-reactive gases only)

  • 66118 Sample Line per Metre

  • 66112 Sample Line Extender (to connect 1/8" sample line together)

  • 66111 Sample Line Extender (to connect 1/8" to 3/16" sample line together)

  • 66478 Hand Aspirator c/w 3m Sample Line

  • 66136 3m Tygon Tubing c/w Sample Connector

  • 66028 Neck Harness with Clip

  • 66546 Neck and Chest Harness with Clip

  • 66017 Probe Assembly

  • 66349 Carrying Case

  • 66545 Ball Float

  • 66930 Reactive Gas Tubing Kit 3m

Chargers
  • 66140 Charger (Universal Plug)

  • 66200 5-way Standard Charger with Universal Plug

  • 66207 10-way Standard Charger with Universal Plug

  • 66206 12v / 24v Vehicle Charger Lead

Fast Chargers
  • 66513 Fast Charger Single

  • 66516 Fast Charger 10-way master,add 66514 to make 10 (requires mains cable)

  • 30061 UK Mains Cable

  • 13439 US Mains Cable

  • 31048 EU Mains Cable

  • 12020 AUS Main Cable

  • 66514 Fast Charger (slave, goes with 66516, up to 9 max)

  • 66209 USB-serial Adaptor

Communication Options
  • 61208 PS500 Datalogging Package (CD-Rom)

  • 61445 PS500 Calibration Package

  • Note: The IR communications interface is included w/datalogging & cal package

Bump Test and Calibration Equipment
  • 61502 Auto Bump/Calibration Station Air + 1 gas inlet

  • 61504 Auto Bump/Calibration Station Air + 3 gas inlets

  • 61504R Auto Bump/Calibration Station Air + 3 gas inlets for Reactive gases

  • 99553 flexiCal Plus (Cal) Package for ABC stations (v1.2.0.0 or newer required)

Battery Packs
  • PS500

  • 66702 Drycell Battery Pack

  • 66701 Long Duration NiMH Battery Pack

  • 66703 Fast Charge Battery Pack
