Carbolite GPC General Purpose Industrial Chamber Furnaces

The Carbolite GPC General Purpose Industrial Chamber Furnaces are large floor-standing models. Available at 1200 °C and 1300 °C with capacities ranging from 131 to 350 litres.

Key Features

  • 1200°C or 1300°C maximum operating temperature
  • 131, 200, 300 or 350 litre chamber volumes
  • Programmable 3216P1 controller
Get a Quote
Carbolite

Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.

The following models have been renamed CWF: GPC 12/36, GPC 13/36, GPC 12/65 & GPC 13/65.

Standard features

  • • Over-temperature protection
  • • Free radiating coiled wire elements on two sides and roof
  • • All models have under hearth heating
  • • Low thermal mass insulation for high energy efficiency
  • • Parallel action door keeps heated surface away from the user
  • • Hard wearing refractory hearth plate resists damage & supports heavier loads
  • • Heating elements are easily serviced

Options (specify these at time of order)

  • • A range of sophisticated digital controllers, multi-segment programmers and data loggers is available. These can be fitted with RS232, RS485 or Ethernet communications
  • • A range of metallic retorts to work with modified atmospheres up to 1150°C
  • • AMS 2750E Nadcap compatible models are available for aerospace applications
  • • Various loading and unloading management options can be supplied

Models
  • GPC12350B-208TX GPC 12/350B 1200°C, 350 litre, Chamber Furnace (200 - 210 V three phase no N)

  • GPC12350B-230TX GPC 12/350B 1200°C, 350 litre, Chamber Furnace (220 - 240 V three phase no N)

  • GPC12350B-400TN GPC 12/350B 1200°C, 350 litre, Chamber Furnace (380 - 415 V three phase + N)

  • GPC13350B-208TX GPC 13/350B 1300°C, 350 litre, Chamber Furnace (200 - 210 V three phase no N)

  • GPC13350B-230TX GPC 13/350B 1300°C, 350 litre, Chamber Furnace (220 - 240 V three phase no N)

  • GPC13350B-400TN GPC 13/350B 1300°C, 350 litre, Chamber Furnace (380 - 415 V three phase + N)
