Testo 521 Differential Pressure Meter

Part Number 0560 5210

Differential pressure meter 0 to 100 hPa incl. battery and calibration protocol.

Highly accurate with internal differential pressure sensor, ideal for inspecting extraction units and ventilators and for monitoring pressure drops in filters. When used with the Pitot tube, the internal pressure sensor measures velocities from 5 - 100 m/s. The 100 Pa probe, which can be connected externally, measures accurately from 1 - 12 m/s.

  Temp. compensated differential pressure sensor built into instrument
  Calculation of velocity and volume flow via Pitot tube measurement
  Multi-point and timed mean calculation
  2 probe sockets for pressure and temperature
  Save data according to site and analyse on PC/notebook
  Direct calculation of velocity speed and volume flow
  Multi-point and timed mean calculation
  Density compensation
  Up to two 4 to 20 mA interfaces connectable to hand-held instr.
  1 analog signal can be evaluated per interface
  Scaling of analog signal in hand-held instrument
  Transmitter can be supplied with power from Testo 521, for example
  4 to 20 mA interface can be connected to Testo 521, 526, 400, 650 und 950 hand-held instruments
  Two user-defined probe inputs allow the connection of external probes for pressure, temperature, current/voltage

Please note - Product designs and specifications are subject to change without notice. The user is responsible for determining the suitability of this product.
