High accuracy ranges from 6millohms to 6ohms.
  Small light weight unit 4kg with NiMh rechargeable batteries
  Data logging with up to 1,000 readings stored with date and time stamp.

The DO7010 is a very rugged and very compact, portable digital ohmmeter for the measurement of low resistance. Using rechargeable and replaceable NiMh batteries with external charger, the DO7010 is capable of measuring with a current of 1 and 10A on all except the highest range.

The DO7010 has been designed with the latest solid state and microprocessor techniques to ensure the very best in measurement reliability and features. The LCD graphic display panel gives full information regarding the measurement configuration, and a single measurement start button ensures that the operation is simple and easy to use.

The measurement may be triggered when the measurement leads are applied to the device under test, ensuring fast single-person operation. The data-logging function also permits up to 1,000 date and time stamped readings to be stored.

Data Sheet

DO7010-BP Additional battery pack 100123
HS01-7010 Duplex handspikes with 3m lead length 190052
HS02-7010 Duplex handspikes with 3 and 15m lead length 190056
LS03-7010 Lead set with 3m leads and terminated with large Kelvin clips type KC3 190043
LS04-7010 Lead set with 3 and 15m lead length terminated in large Kelvin clips type KC3 190047
MTS3 Calibration Standard 930242
RSL04 RS232 interface cable 1m 920069
